Deep Learning

Deep Learning

1. Basics of Neural Networks

Simple Theory: Brain-like Computing

Neural networks are inspired by how our brain works. Imagine you’re learning to recognize cats:

  • Your eyes (input) see an animal
  • Your brain neurons process features (whiskers, ears, tail)
  • After several “thought layers”, you conclude “cat” (output)

In code terms:

  • Input layer: Receives data (like pixel values)
  • Hidden layers: Process information (detect edges, shapes)
  • Output layer: Makes final decision (cat or not cat)

Learning Roadmap

  1. Start with basic neural networks (perceptrons)
  2. Move to CNNs for image tasks
  3. Explore RNNs for sequence data
  4. Learn NLP fundamentals
  5. Practice building end-to-end models
  6. Master evaluation and optimization
  7. Finally leverage transfer learning

Remember: Deep learning is like learning an instrument – regular practice with small examples leads to mastery over time!

Step-by-Step Explanation of Each Program

(Line-by-line breakdown with detailed explanations for beginners)

1. perceptron.py – Basics of Neural Networks

(A simple perceptron implementing an AND gate logic)

Code Breakdown:

import numpy as np  # Import NumPy for numerical operations
  • numpy is a library for numerical computing in Python.
  • We use it for array operations and mathematical functions.
class Perceptron:
    def __init__(self, input_size):
        self.weights = np.random.rand(input_size)  # Initialize random weights
        self.bias = np.random.rand()  # Initialize random bias
  • __init__: Constructor method that initializes the perceptron.
  • input_size: Number of input features (e.g., 2 for AND gate).
  • self.weights: Random weights (e.g., [0.3, 0.7]).
  • self.bias: Random bias (e.g., 0.5).
    def predict(self, inputs):
        calculation = np.dot(inputs, self.weights) + self.bias
        return 1 if calculation > 0 else 0  # Step activation function
  • predict(): Takes input and returns prediction (0 or 1).
  • np.dot(inputs, weights): Computes weighted sum (e.g., input1 * weight1 + input2 * weight2).
  • + bias: Adds bias to shift the decision boundary.
  • 1 if calculation > 0 else 0: Step function (outputs 1 if sum > 0, else 0).
if __name__ == "__main__":
    perceptron = Perceptron(2)  # Create perceptron with 2 inputs
    perceptron.weights = np.array([1, 1])  # Manually set weights for AND gate
    perceptron.bias = -1.5  # Set bias for AND logic
  • if __name__ == "__main__":: Ensures code runs only when script is executed directly.
  • perceptron = Perceptron(2): Creates a perceptron with 2 inputs.
  • weights = [1, 1]: Manually set (normally learned via training).
  • bias = -1.5: Threshold for AND gate (ensures 0 AND 0 = 0, 1 AND 1 = 1).
    test_inputs = [np.array([0, 0]), np.array([0, 1]),
                   np.array([1, 0]), np.array([1, 1])]

    print("AND Gate Results:")
    for x in test_inputs:
        print(f"{x} -> {perceptron.predict(x)}")
  • test_inputs: All possible AND gate inputs.
  • for x in test_inputs:: Tests each input combination.
  • perceptron.predict(x): Predicts output (0 or 1).

Expected Output:

[0 0] -> 0
[0 1] -> 0
[1 0] -> 0
[1 1] -> 1

(Matches AND gate logic!)

pip install tensorflow
pip install keras

2. simple_cnn.py – CNN for MNIST Digit Classification

(A basic CNN to recognize handwritten digits from the MNIST dataset)

Code Breakdown:

import tensorflow as tf
from tensorflow.keras import layers, models
  • tensorflow: Deep learning framework.
  • layers: Contains neural network layers (Conv2D, Dense, etc.).
  • models: Helps in building Sequential models.
def build_cnn():
    model = models.Sequential([
        layers.Conv2D(32, (3, 3), activation='relu', input_shape=(28, 28, 1)),
        layers.MaxPooling2D((2, 2)),
        layers.Flatten(),
        layers.Dense(10, activation='softmax')
    ])
  • Sequential(): Linear stack of layers.
  • Conv2D(32, (3,3)): 32 filters, each 3×3 (detects edges, textures).
  • MaxPooling2D((2,2)): Downsamples image (reduces computation).
  • Flatten(): Converts 2D features to 1D for Dense layer.
  • Dense(10, activation='softmax'): Output layer (10 digits, probabilities).
    model.compile(optimizer='adam',
                  loss='sparse_categorical_crossentropy',
                  metrics=['accuracy'])
    return model
  • compile(): Configures model for training.
  • optimizer='adam': Adaptive learning rate optimizer.
  • loss='sparse_categorical_crossentropy': Loss function for classification.
  • metrics=['accuracy']: Tracks accuracy during training.
if __name__ == "__main__":
    (train_images, train_labels), (test_images, test_labels) = tf.keras.datasets.mnist.load_data()
  • mnist.load_data(): Loads MNIST dataset (60k train, 10k test images).
    train_images = train_images.reshape((60000, 28, 28, 1)).astype('float32') / 255
    test_images = test_images.reshape((10000, 28, 28, 1)).astype('float32') / 255
  • reshape((60000, 28, 28, 1)): Reshapes images to (height, width, channels).
  • / 255: Normalizes pixel values (0-255 → 0-1).
    model = build_cnn()
    model.fit(train_images, train_labels, epochs=2, batch_size=64,
              validation_data=(test_images, test_labels))
  • model.fit(): Trains the model.
  • epochs=2: Number of training cycles.
  • batch_size=64: Samples processed before weight update.
  • validation_data: Tests model on unseen data.

3. simple_rnn.py – Time Series Prediction with RNN

(Predicts the next value in a sine wave sequence)

Code Breakdown:

def generate_time_series_data(n_samples=1000, n_steps=20):
    time = np.linspace(0, 100, n_steps * n_samples)
    data = np.sin(time).reshape(n_samples, n_steps, 1)
    X = data[:, :-1]  # All steps except last
    y = data[:, 1:]   # All steps shifted by 1
    return X, y
  • np.linspace(): Generates evenly spaced numbers.
  • np.sin(time): Creates sine wave.
  • reshape(n_samples, n_steps, 1): Formats for RNN (samples, timesteps, features).
  • X = data[:, :-1]: Input sequences (first 19 steps).
  • y = data[:, 1:]: Target sequences (next 19 steps).
def build_rnn():
    model = Sequential([
        SimpleRNN(32, return_sequences=True, input_shape=[None, 1]),
        Dense(1)
    ])
    model.compile(optimizer='adam', loss='mse')
    return model
  • SimpleRNN(32): RNN with 32 memory units.
  • return_sequences=True: Returns output at each timestep (for sequence prediction).
  • Dense(1): Outputs predicted next value.
  • loss='mse': Mean Squared Error (for regression).
    test_sequence = np.sin(np.linspace(0, 2*np.pi, 20)).reshape(1, 20, 1)
    prediction = model.predict(test_sequence)
    print("Next value prediction:", prediction[0, -1, 0])
  • test_sequence: New sine wave sequence.
  • prediction: Forecasts next value.

4. nlp_sentiment.py – Sentiment Analysis with NLP

(Classifies text as positive or negative)

Key Steps:

  1. Tokenization: Converts text to numbers.
   tokenizer = Tokenizer(num_words=100)
   tokenizer.fit_on_texts(texts)
   sequences = tokenizer.texts_to_sequences(texts)
   padded_sequences = pad_sequences(sequences, maxlen=5)
  • Tokenizer: Maps words to integers.
  • pad_sequences: Ensures equal length (padding with zeros).
  1. Embedding Layer:
   Embedding(100, 8, input_length=5)
  • Converts word IDs to dense vectors (learns word meanings).
  1. Training & Prediction:
   model.fit(padded_sequences, labels, epochs=10)
   test_text = ["This was great"]
   test_seq = tokenizer.texts_to_sequences(test_text)
   print(model.predict(test_padded))
  • Predicts sentiment (0=negative, 1=positive).

5. transfer_learning.py – Using Pre-trained VGG16

(Reuses a trained CNN for custom tasks)

Key Steps:

  1. Load Pre-trained Model:
   base_model = VGG16(weights='imagenet', include_top=False, input_shape=(150, 150, 3))
  • include_top=False: Removes final classification layer.
  1. Freeze Layers:
   for layer in base_model.layers:
       layer.trainable = False
  • Prevents pre-trained weights from updating.
  1. Add Custom Layers:
   model = Sequential([
       base_model,
       Flatten(),
       Dense(256, activation='relu'),
       Dense(1, activation='sigmoid')
   ])
  • New layers learn task-specific features.

6. model_evaluation.py – Cross-Validation & Metrics

(Evaluates model performance)

Key Steps:

  1. Cross-Validation:
   scores = cross_val_score(model, X_train, y_train, cv=5)
   print(f"Accuracy: {scores.mean():.2f} (+/- {scores.std():.2f})")
  • Splits data into 5 folds, trains/evaluates on each.
  1. Classification Report:
   print(classification_report(y_test, y_pred))
  • Shows precision, recall, F1-score.
